| | IntRegNode () |
| |
| | IntRegNode (std::shared_ptr< Node::NodeImpl > pInteger) |
| |
| virtual | ~IntRegNode () |
| |
| virtual void | SetReference (INode *pBase) |
| | overload SetReference for Value
|
| |
| | IntegerNode () |
| |
| | IntegerNode (std::shared_ptr< Node::NodeImpl > pInteger) |
| |
| virtual | ~IntegerNode () |
| |
| virtual void | SetValue (int64_t Value, bool Verify=true) |
| | Set node value.
|
| |
| virtual IInteger & | operator= (int64_t Value) |
| | Set node value.
|
| |
| virtual int64_t | GetValue (bool Verify=false, bool IgnoreCache=false) |
| | Get node value.
|
| |
| virtual int64_t | operator() () |
| | Get node value.
|
| |
| virtual int64_t | operator* () |
| | Get node value.
|
| |
| virtual int64_t | GetMin () |
| | Get minimum value allowed.
|
| |
| virtual int64_t | GetMax () |
| | Get maximum value allowed.
|
| |
| virtual EIncMode | GetIncMode () |
| | Get increment mode.
|
| |
| virtual int64_t | GetInc () |
| | Get increment.
|
| |
| virtual int64_autovector_t | GetListOfValidValues (bool bounded=true) |
| | Get list of valid value.
|
| |
| virtual ERepresentation | GetRepresentation () |
| | Get recommended representation.
|
| |
| virtual GenICam::gcstring | GetUnit () |
| | Get the physical unit name.
|
| |
| virtual IFloat * | GetFloatAlias () |
| | gets the interface of an alias node.
|
| |
| virtual void | ImposeMin (int64_t Value) |
| | Restrict minimum value.
|
| |
| virtual void | ImposeMax (int64_t Value) |
| | Restrict maximum value.
|
| |
| virtual void | SetReference (INode *pBase) |
| | overload SetReference for Integer
|
| |
| | ValueNode () |
| | Constructor.
|
| |
| | ValueNode (std::shared_ptr< Node::NodeImpl > pValue) |
| | constructor with GenICam IValue
|
| |
| | ~ValueNode () |
| | Destructor.
|
| |
| virtual INode * | GetNode () |
| |
| virtual GenICam::gcstring | ToString (bool Verify=false, bool IgnoreCache=false) |
| | Get content of the node as string.
|
| |
| virtual void | FromString (const GenICam::gcstring &ValueStr, bool Verify=true) |
| | Set content of the node as string.
|
| |
| virtual bool | IsValueCacheValid () const |
| | Checks if the value comes from cache or is requested from another node.
|
| |
| virtual void | SetReference (INode *pBase) |
| | overload SetReference for Value
|
| |
| | Node () |
| | Constructor.
|
| |
| | Node (std::shared_ptr< Node::NodeImpl > pNodeHandle) |
| | Constructor.
|
| |
| | ~Node () |
| | Destructor.
|
| |
| virtual GenICam::gcstring | GetName (bool FullQualified=false) const |
| | Get node name.
|
| |
| virtual GenApi::ENameSpace | GetNameSpace () const |
| | Get name space.
|
| |
| virtual EVisibility | GetVisibility () const |
| | Get the recommended visibility of the node.
|
| |
| virtual void | InvalidateNode () |
| | Indicates that the node's value may have changed.
|
| |
| virtual bool | IsCachable () const |
| | Is the node value cacheable.
|
| |
| virtual EYesNo | IsAccessModeCacheable () const |
| | True if the AccessMode can be cached.
|
| |
| virtual ECachingMode | GetCachingMode () const |
| | Get Caching Mode.
|
| |
| virtual int64_t | GetPollingTime () const |
| | recommended polling time (for not cacheable nodes)
|
| |
| virtual GenICam::gcstring | GetToolTip () const |
| | Get a short description of the node.
|
| |
| virtual GenICam::gcstring | GetDescription () const |
| | Get a long description of the node.
|
| |
| virtual GenICam::gcstring | GetDisplayName () const |
| | Get a name string for display.
|
| |
| virtual GenICam::gcstring | GetDeviceName () const |
| | Get a name of the device.
|
| |
| virtual void | GetChildren (GenApi::NodeList_t &Children, ELinkType LinkType=ctReadingChildren) const |
| | Get all nodes this node directly depends on.
|
| |
| virtual void | GetParents (GenApi::NodeList_t &Parents) const |
| | Gets all nodes this node is directly depending on.
|
| |
| virtual void | GetLockNodes (GenApi::NodeList_t &LockNodes) const |
| | Gets all nodes which can directly lock this node.
|
| |
| virtual CallbackHandleType | RegisterCallback (CNodeCallback *pCallback) |
| | Register change callback Takes ownership of the CNodeCallback object.
|
| |
| virtual bool | DeregisterCallback (CallbackHandleType hCallback) |
| | De register change callback Destroys CNodeCallback object.
|
| |
| virtual INodeMap * | GetNodeMap () const |
| | Retrieves the central node map.
|
| |
| virtual GenICam::gcstring | GetEventID () const |
| | Get the EventId of the node.
|
| |
| virtual bool | IsStreamable () const |
| | True if the node is streamable.
|
| |
| virtual void | GetPropertyNames (GenICam::gcstring_vector &PropertyNames) const |
| | Returns a list of the names all properties set during initialization.
|
| |
| virtual bool | GetProperty (const GenICam::gcstring &PropertyName, GenICam::gcstring &ValueStr, GenICam::gcstring &AttributeStr) |
| | Retrieves a property plus an additional attribute by name If a property has multiple values/attribute they come with Tabs as delimiters.
|
| |
| virtual void | ImposeAccessMode (EAccessMode ImposedAccessMode) |
| | Imposes an access mode to the natural access mode of the node.
|
| |
| virtual void | ImposeVisibility (EVisibility ImposedVisibility) |
| | Imposes a visibility to the natural visibility of the node.
|
| |
| virtual INode * | GetAlias () const |
| | Retrieves the a node which describes the same feature in a different way.
|
| |
| virtual INode * | GetCastAlias () const |
| | Retrieves the a node which describes the same feature so that it can be casted.
|
| |
| virtual GenICam::gcstring | GetDocuURL () const |
| | Gets a URL pointing to the documentation of that feature.
|
| |
| virtual bool | IsDeprecated () const |
| | True if the node should not be used any more.
|
| |
| virtual EInterfaceType | GetPrincipalInterfaceType () const |
| | Get the type of the main interface of a node.
|
| |
| virtual bool | IsFeature () const |
| | True if the node can be reached via category nodes from a category node named "Root".
|
| |
| void | SetNodeHandle (std::shared_ptr< Node::NodeImpl > pNodeHandle) |
| | Set Node handle.
|
| |
| std::shared_ptr< Node::NodeImpl > | GetNodeHandle () const |
| | Get Node handle.
|
| |
| virtual EAccessMode | GetAccessMode () const |
| | Base interface overrides.
|
| |
| virtual bool | IsSelector () const |
| | Selector interface overrides.
|
| |
| virtual void | GetSelectedFeatures (FeatureList_t &) const |
| | retrieve the group of selected features
|
| |
| virtual void | GetSelectingFeatures (FeatureList_t &) const |
| | retrieve the group of features selecting this node
|
| |
| virtual void | SetReference (INode *pBase) |
| | Reference interface overrides \ingroup Spinnaker_GenApi_PublicImpl.
|
| |
| virtual void | SetReference (ISelector *pBase) |
| |
| void | SetNodeMap (INodeMap *pNodeMap) |
| |
| virtual bool | operator== (int nullPtr) const |
| |
| virtual bool | operator!= (int nullPtr) const |
| |
| | RegisterNode () |
| |
| | RegisterNode (std::shared_ptr< Node::NodeImpl > pRegister) |
| |
| virtual | ~RegisterNode () |
| |
| virtual void | Set (const uint8_t *pBuffer, int64_t Length, bool Verify=true) |
| | Set the register's contents.
|
| |
| virtual void | Get (uint8_t *pBuffer, int64_t Length, bool Verify=false, bool IgnoreCache=false) |
| | Fills a buffer with the register's contents.
|
| |
| virtual int64_t | GetLength () |
| | Retrieves the Length of the register [Bytes].
|
| |
| virtual int64_t | GetAddress () |
| | Retrieves the Address of the register.
|
| |
| virtual void | SetReference (INode *pBase) |
| | overload SetReference for Register
|
| |
Interface for string properties.
Public Member Functions inherited from IntegerNode
